Ultra Slim Digital Multi Color Flexible SMD LED Strip
PACK OF 1 REEL(5Meters) Led Strip with Transformer, Controller & Remote(LTC-6500)
Technical Data:
Emitted Color : RGB
Dimension. : W1.2 x H0.2 x L500(cm)
LEDs Source : 5050 SMD LEDs
LEDs Q'ty : 160pcs (32pcs per meter)
Viewing Angle : 120 Degree
Forward Voltage for the RGB LED Strip : 5v
Forward Voltage for the Controller : 12v
Number of LEDs/Per Cutting Unit : 2pcs
IP68 Waterproof Rated
Included One 12v Power Supply, One 5v Power Supply, One Controller w/ Remote
Features
- Voltage of LED DC5V, Voltage of signal DC12V
- Match with dream color controller RGB LED, Provide 83 different changing patterns and 100 different changing speeds
- LEDs are Solid State, High Shock/Vibration Resistant
- LEDs Run on Low Power Consumption, High Intensity
- Produce Little to No Heat- Long Life 100,000+ hrs (10+ Years)
- Major Reduction in Power Costs- No RF Interference
- Maintenance Free - Mercury Free - Glass Free
- Flexible & Slim Form, 3M Double Tape, Cuttable at every 2 LEDs
Amazing Wireless-Dream-color LCD Controller: This controller is design for led production which use HL1606 as driver ,it is very useful for light box advertisement, stage light, house decorating, and so on. Specification:
- Working temperature: -20- 60 ¢FFFJ
- Supply voltage: DC12V
- Product size: L90!NW60!NH25mm
- Weight:75g
- Consume power:2.2W
- Output:Tow group SPI signal Function&Feature:
- Length setup function
- A lot of programs to chose
- Memory function
- 128*128*128 grayscale Connecting diagram:
(Click it to Enlarge)
Function of controller panel :  ON/OFF button, it can open or close led anytime, when led is on the station of closing, The LCD will display !!!OIC NUMBER: ***!!L,!!!O***!!Lis the value of current setting.
 Play/pause button, when you want to see the static effection of led ,you may press this button to pause.
 Adding button, to add the IC NUMBER, the most number is 255 (510 group of RGB)
 Reducing button, to reduce the IC NUMBER, the least number is 16 (32 group of RGB)
 Program choosing button, up direction!Athere are 83 programs in all.
 Program choosing button-down direction.
 Speed slow button, there are 100 step in all, the most number is 100
 Speed quick button, the least number is 1
Function of remote panel: - ON/OFF: ON/OFF button!Ait can open or close led anytime, when led is on the station of closing, The LCD will display !!!OIC NUMBER: ***!!L,!!!O***!!Lis the value of current setting.
- MODE: Play/pause button, when you want to see the static affection of led ,you may press this button to pause.
- S+: Speed quick button, the least number is 1
- S-: Speed slow button, there are 100 step in all, the most number is 100
- B+: Program choosing button, up direction,there are 83 programs in all.
- B-: Program choosing button, down direction. OUTPUT1&OUTPUT2 Description: L, K ,D, S is the corresponding signal of HL1606,which is L_I, CK_I, D_I, S_I.
PROGRAM Description: !]Condition!GA1!XBlue LED!FA2!XRed LED!FA3!XGreen LED!^
1 All color wave forward direction
2 All color wave backward direction
3 All color draw curtain by waving
4 All color lower curtain by waving
5 Three color wave by wave forward direction
6 Three color wave by wave backward direction
7 Three color draw curtain waving by waving
8 Three color lower curtain waving by waving
9 Many color wave forward direction
10 Many color wave backward direction
11 Many color wave draw curtain
12 Many color wave lower curtain
13 Six color trail forward direction
14 Six color trail backward direction
15 Six color trail draw curtain
16 Six color trail lower curtain
17 Three base color trail forward direction
18 Three base color trail backward direction
19 Three base color trail draw curtain
20 Three base color trail lower curtain
21 Six color jumpy change
22 Three base color jumpy change
23 Three mixxing color jumpy change
24 Six color jumpy change forward direction
25 Six color jumpy change backward direction
26 Six color jumpy change draw curtain
27 Six color jumpy change lower curtain
28 Three base color jumpy change forward direction
29 Three base color jumpy change backward direction
30 Three base color jumpy change draw curtain
31 Three base color jumpy change lower curtain
32 Six color brush forward direction
33 Six color brush backward direction
34 Three base color brush forward direction
35 Three base color brush backward direction
36 Six color brush draw curtain
37 Six color brush lower curtain
38 Three base color brush draw curtain
39 Three base color brush lower curtain
40 Change color red-purple-red forward direction
41 Change color red-purple-red forward direction
42 Change color red-purple-red backward direction | 43 Change color red-purple-red draw curtain
44 Change color red-purple-red lower curtain
45 Change color red-yellow-red forward direction
46 Change color red-yellow-red backward direction
47 Change color red-yellow-red draw curtain
48 Change color red-yellow-red lower curtain
49 Change color red-green-red forward direction
50 Change color red-green-red backward direction
51 Change color red-green-red draw curtain
52 Change color red-green-red lower curtain
53 Change color red-blue-red forward direction
54 Change color red-blue-red backward direction
55 Change color red-blue-red draw curtain
56 Change color red-blue-red lower curtain
57 Change color green-cyan-green forward direction
58 Change color green-cyan-green backward direction
59 Change color green-cyan-green draw curtain
60 Change color green-cyan-green lower curtain
61 Change color green-blue-green forward direction
62 Change color green-blue-green backward direction
63 Change color green-blue-green draw curtain
64 Change color green-blue-green lower curtain
65 Change color red-white-red forward direction
66 Change color red-white-red backward direction
67 Change color red-white-red draw curtain
68 Change color red-white-red lower direction
69 Change color green-white-green forward direction
70 Change color green-white-green backward direction
71 Change color green-white-green draw curtain
72 Change color green-white-green lower direction
73 Change color blue-white-blue forward direction
74 Change color blue-white-blue backward direction
75 Change color blue-white-blue draw curtain
76 Change color blue-white-blue lower curtain
77 Six color fade in and fade out forward direction
78 Six color fade in and fade out backward direction
79 Six color fade in and fade out draw curtain
80 Six color fade in and fade out lower curtain
81 Three base color fade in and fade out forward direction
82 Three base color fade in and fade out backward direction
83 Three base color fade in and fade out draw curtain
85 Three base color fade in and fade out lower curtain |
Safety Information:
- Supply voltage of this product is DC12V never connect to DC24V or AC220V directly
- Never connect two wires directly in case of short circuit
- Lead wire should be connected correctly according to colors that connecting diagram
- Warranty of this product is one year, in this period we guarantee replacement or repairing with no charge, but exclude the artificial situation of damaged. Product Photo
Full Set Digital RGB Led Strip
